Hide Duplicated Details
DJI Power 500
DJI Power 1000
General
Model
DYM500L/DYM500H
DYM1000L/DYM1000H
Capacity
512 Wh
1024 Wh
Net Weight
Approx. 7.3 kg
Approx. 13 kg
Dimensions
305×207×177 mm (L×W×H)
448×225×230 mm (L×W×H)
Number of Ports
AC Output × 2
USB-C × 2
USB-A × 2
SDC Lite × 1
AC Input × 1
USB-C × 2
USB-A × 2
SDC Lite × 1
AC Input × 1
AC Output × 2
USB-C × 2
USB-A × 2
SDC × 1
SDC Lite × 1
AC Input × 1
USB-C × 2
USB-A × 2
SDC × 1
SDC Lite × 1
AC Input × 1
Max Operating Altitude
3000 m
3000 m
Output Specifications
AC Output
DYM500L: AC 100-120 V, 50/60 Hz, rated: 800 W, max continuous output: 1000 W
DYM500H: AC 220-240 V, 50/60 Hz, rated: 800 W, max continuous output: 1000 W
Max continuous output power is available when the product's battery level is above 20%. AC output data varies by country and region.
DYM500H: AC 220-240 V, 50/60 Hz, rated: 800 W, max continuous output: 1000 W
Max continuous output power is available when the product's battery level is above 20%. AC output data varies by country and region.
DYM1000L: AC 100-120 V, 50/60 Hz, max continuous output: 2200 W, [1] max output: 2600 W (total), [2] peak output: 4400 W
DYM1000H: AC 220-240 V, 50/60 Hz, max continuous output: 2200 W, [1] max output: 2600 W (total), [2] peak output: 4400 W
AC output data varies by country and region.
Given that the voltage in Japan is 100 V, the max continuous output power of the Japanese version is 2000 W.
1. At a room temperature of 25° C (77° F), Power 1000 can stably provide a max continuous output of 2200 W until the battery runs out. Data measured in a DJI laboratory.
2. At an output power of 2600 W, the DYM1000L prototype can sustain for 30 seconds, and the DYM1000H prototype can sustain for 60 seconds. Durations were measured when DJI Power 1000 is at approx. 25° C (77° F) and 50% battery level. Duration may vary due to differences in battery temperature and battery level. Refer to the actual usage. It is recommended to use max power output when the battery is at a moderate temperature and a relatively higher battery level. Data measured in a DJI laboratory.
DYM1000H: AC 220-240 V, 50/60 Hz, max continuous output: 2200 W, [1] max output: 2600 W (total), [2] peak output: 4400 W
AC output data varies by country and region.
Given that the voltage in Japan is 100 V, the max continuous output power of the Japanese version is 2000 W.
1. At a room temperature of 25° C (77° F), Power 1000 can stably provide a max continuous output of 2200 W until the battery runs out. Data measured in a DJI laboratory.
2. At an output power of 2600 W, the DYM1000L prototype can sustain for 30 seconds, and the DYM1000H prototype can sustain for 60 seconds. Durations were measured when DJI Power 1000 is at approx. 25° C (77° F) and 50% battery level. Duration may vary due to differences in battery temperature and battery level. Refer to the actual usage. It is recommended to use max power output when the battery is at a moderate temperature and a relatively higher battery level. Data measured in a DJI laboratory.
AC Output (Bypass Mode)
DYM500L: AC 100-120 V, max 1000 W
DYM500H: AC 220-240 V, max 1000 W
DYM500H: AC 220-240 V, max 1000 W
DYM1000L: AC 100-120 V, 12 A,
1440 W
DYM1000H: AC 220-240 V, 10 A,
2200 W
1440 W
DYM1000H: AC 220-240 V, 10 A,
2200 W
USB-A Output
5 V, 3 A
9 V, 2 A
12 V, 2 A
Max output power per channel: 24 W
9 V, 2 A
12 V, 2 A
Max output power per channel: 24 W
5 V, 3 A
9 V, 2 A
12 V, 2 A
Max output power per channel: 24 W
9 V, 2 A
12 V, 2 A
Max output power per channel: 24 W
USB–C Output
5 V, 5 A
9 V, 5 A
12 V, 5 A
15 V, 5 A
20 V, 5 A
Max output power per channel: 100 W*
* During power output, the device being charged must support the PD 3.0 protocol.
9 V, 5 A
12 V, 5 A
15 V, 5 A
20 V, 5 A
Max output power per channel: 100 W*
* During power output, the device being charged must support the PD 3.0 protocol.
5 V, 5 A
9 V, 5 A
12 V, 5 A
15 V, 5 A
20 V, 5 A
28 V, 5 A (EPR)
Max output power per channel: 140 W*
* Each USB-C port supports a max output power of 140 W. The device being charged must support the PD 3.1 protocol and use a USB cable that meets EPR specifications.
9 V, 5 A
12 V, 5 A
15 V, 5 A
20 V, 5 A
28 V, 5 A (EPR)
Max output power per channel: 140 W*
* Each USB-C port supports a max output power of 140 W. The device being charged must support the PD 3.1 protocol and use a USB cable that meets EPR specifications.
SDC and SDC Lite Output
SDC Lite: 9-27 V, max output power: 240 W
SDC: 9-27 V, max current: 10 A, max output power: 240 W
SDC Lite: 9-27 V, max current: 10 A, max output power: 240 W
SDC and SDC Lite ports support extensive accessories.
SDC Lite: 9-27 V, max current: 10 A, max output power: 240 W
SDC and SDC Lite ports support extensive accessories.
Input Specifications
AC Input
DYM500L: AC 100-120 V, 540 W (recharging), 1000 W (Bypass mode)
DYM500H: AC 220-240 V, 540 W (recharging), 1000 W (Bypass mode)
DYM500H: AC 220-240 V, 540 W (recharging), 1000 W (Bypass mode)
DYM1000L: AC 100-120 V, 1200 W (recharging), 1440 W (Bypass mode)
DYM1000H: AC 220-240 V, 1200 W (recharging), 2200 W (Bypass mode)
DYM1000H: AC 220-240 V, 1200 W (recharging), 2200 W (Bypass mode)
SDC and SDC Lite Input
SDC Lite: DC 22.4-29.2 V, max 300 W, 10 A
The SDC Lite port supports extensive accessories.
The SDC Lite port supports extensive accessories.
SDC: DC 32-58.4 V,
max 400 W, 8 A
SDC Lite: DC 32-58.4 V,
max 400 W, 8 A
SDC and SDC Lite ports support extensive accessories.
max 400 W, 8 A
SDC Lite: DC 32-58.4 V,
max 400 W, 8 A
SDC and SDC Lite ports support extensive accessories.
USB–C Input
DC 5-20 V, max 100 W*
Supports simultaneous power input with two USB-C ports at a max 200 W.
During power output, the device being charged must support the PD 3.0 protocol.
Supports simultaneous power input with two USB-C ports at a max 200 W.
During power output, the device being charged must support the PD 3.0 protocol.
N/A
Battery
Cell Chemistry
LFP (lithium ferrophosphate)
LFP (lithium ferrophosphate)
Cycle Life
Maintains over 70% capacity after 4000 cycles.
Measured under 25° C (77° F) laboratory conditions, being recharged in the 270W Standard Recharge Mode, and at an output power of 500 W.
Measured under 25° C (77° F) laboratory conditions, being recharged in the 270W Standard Recharge Mode, and at an output power of 500 W.
Maintains over 70% capacity after 4000 cycles.
Measured at 25° C (77° F) room temperature, being recharged in the 600W Standard Recharge Mode, and at an output power of 1000 W.
Measured at 25° C (77° F) room temperature, being recharged in the 600W Standard Recharge Mode, and at an output power of 1000 W.
Operating Temperature
Power Supply Temperature
-10° to 45° C (14° to 113° F)
-10° to 45° C (14° to 113° F)
Recharging Temperature
0° to 45° C (32° to 113° F)
0° to 45° C (32° to 113° F)
Storage Temperature
-10° to 45° C (14° to 113° F)
-10° to 45° C (14° to 113° F)
